The United States Capitol dome is the dome situated above the United States Capitol which reaches upwards to 288 feet (88 m) in height and 96 feet (29 m) in diameter. The dome was designed by Thomas U. Walter, the fourth Architect of the Capitol, and constructed between 1855 and 1866 at a cost of $1,047,291 (equivalent to $220 million in 2013). The dome is not stone, but cast iron carefully painted to appear to be made of the same stone as the main capitol building. It is actually two domes, one inside the other, and the total weight is 14.1 million pounds (6,400 t) pounds.
First dome
The current cast iron dome of the United States Capitol is the second dome to sit above the building. The origin of the first dome began with the Capitol design contest sponsored by Secretary of State Thomas Jefferson, at the behest of President George Washington, in 1792. The winner of the contest, Doctor William Thornton, called for a dome in his original design for the building. Most vividly, Thornton drew upon the Roman Pantheon for inspiration with the Neoclassical dome and associated portico.
Thornton's replacement, Benjamin Henry Latrobe, the second Architect of the Capitol, altered Thornton's design plan on the exterior by adding an octagonal drum to visually separate the bottom of the dome from the top of the building's pediment. The third Architect of the Capitol, Charles Bulfinch, altered the exterior profile of the plans still further by increasing the dome's height, which he later wrote was at the insistence of the President and Congress.
In 1822, Bulfinch requested funds for the construction of the center of the building, and President Monroe signed off on an appropriation of $120,000. This included the building of a double-dome structure, a stone, brick, and wooden interior dome to rise 96 feet (29 m) above the rotunda floor (matching the dimensions of the Pantheon), and a wooden exterior dome covered in copper that would rise to 140 feet (43 m). Set at the crown of the exterior dome was an oculus 24 feet (7.3 m) wide, which provided illumination to the rotunda floor below. Bulfinch completed the project in 1823.
For more than two decades, the green copper dome of the Capitol greeted visitors to the nation's capitol, until the 1850s. Due to the growth of the United States and the expansion and addition of new states, the size of the United States Congress had grown accordingly and pushed the limits of the capacity of the Capitol. Under the guidance of the fourth Architect of the Capitol, Thomas U. Walter, extensions were built onto the north and south wings of the building. In the process, the new, longer building made the original Bulfinch dome appear aesthetically displeasing (and it had in any case been the source of much prior criticism). Congress, after lobbying by Walter and Montgomery C. Meigs (then Supervising Engineer), passed legislation to build a bigger dome in 1855.
Second (current) dome
Plans began in May 1854 to build a new cast-iron dome for the United States Capitol, sold on the aesthetics of a new dome, as well as the utility of a fire-proof one. Influenced by the great domes of Europe, Walter paid particular attention to the Pantheon of Paris, St Paul's Cathedral in London and St. Peter's Basilica in Rome. William Allen, Historian of the Capitol, described Walter's first design as,
"...a tall, ellipsodial dome standing on a two-story drum with a ring of forty columns forming a peristyle surrounding the lower half of the drum. The upper part of the drum was enriched with decorated pilasters upholding a bracketed attic. Crowning the composition was a statue standing on a slender, columned tholus..."
Walter drafted a seven-foot (2.1 m) drawing of the aforementioned design and displayed it in his office, where it drew the excited attention of members of Congress in 1854. A year later, on March 3, 1855, President Franklin Pierce signed off on the appropriation of $100,000 (equivalent to $36.9 million in 2013) to build the dome. Construction began after some practical changes to the original design (such as the reduction of the columns from 40 to 36) in September of that year with the removal of the dome raised by Charles Bulfinch. A unique scaffold was built inside the rotunda, designed to keep weight away from the weak center area of the floor, and a crane was set within to run on a steam-powered engine (fueled from the salvaged wood from the old dome).
Over the next 11 years, the dome designed with an interior dome and exterior dome rose over the nation's capitol. By December 2, 1863, Walter was able to set the Statue of Freedom atop the dome. This was not accomplished until after Walter had been forced to revise the design of the dome to handle the statue, which had been delivered taller and heavier than requested. Yet, the man who designed the dome did not see its total completion, because Thomas Walter resigned in 1865. His replacement, Edward Clark, assumed the role of finishing the last aspects of the dome. Just over a month later, in January 1866, Constantino Brumidi--who had been hired to paint a fresco on a platform above the interior dome's oculus--removed the scaffolding used during his work on the Apotheosis of Washington. This signaled the end of construction for the United States Capitol dome.
Some 8,909,200 pounds (4,041.1 t) of iron were ultimately used in the construction that ran virtually 11 years. Inside, the interior dome rises to 180 feet (55 m) over the rotunda floor, and outside, the exterior dome ascends to 288 feet (88 m) including the height of the Statue of Freedom. The total cost of the dome was valued at $1,047,291 (equivalent to $220 million in 2013).
Visitation of the dome is highly restricted, usually offered only to members of Congress and their select guests. When looking up from the rotunda floor, the railing some 180 feet (55 m) above is barely visible. Visitors ascend a series of metal stairs between the inner and outer domes. They eventually wind their way to a balcony just underneath the Apotheosis of Washington. From this view, the painting is curved and distorted. From the balcony, metal stairs take visitors over the painting and up to the outside balcony under the tholos directly beneath the Statue of Freedom. Additional stairs lead up into the statue for maintenance.
Within the columned tholus upon which stands the Statue of Freedom, there are two lights which serve as signifiers to the people of Washington and the nation that either one or both houses of Congress are in night sessions. The white light signifies that the House of Representatives is in night session. The red light signifies that the Senate is in night session. When both white and red lights burn together, they signify that the two houses of Congress are each in night sessions or that the two houses are in joint night session.
Restoration and conservation of the Capitol Dome's cantilevered peristyle and skirting occurred in 2012. In 2013, the Architect of the Capitol announced a tentative four-year, $10 million project to repair and conserve the Capitol dome. The project involved both interior work to the rotunda, and exterior work on the dome. The proposal would require erecting white scaffolding around the dome, stripping the paint, repairing the ironwork, repainting the dome, and installing new lighting. The work was needed because the dome, which last underwent repair and conservation in 1960, was rusting and some ironwork had fallen from the structure. Congress had appropriated no funds for the project, however.
A $60 million, two-year project to start in early 2014 includes removing paint, priming and quickly repainting. Steel pins and "metal stitching" will be used to repair cracks, and water damage inside will be fixed.
